The area of any circle is equal to a right-angled triangle in which one of the sides about the right angle is equal to the radius, and the other to the circumference, of the circle.
任意圆的面积,等于一个直角三角形;这个三角形的一条直角边等于圆半径,另一条直角边等于圆周长。
圆心 O、半径 OA、内接八边形和外切正方形给出阿基米德的基本夹逼图式。内接边界从圆内逼近,外切边界从圆外逼近。
If the circle were greater than the comparison triangle K, keep bisecting arcs and inscribe a polygon until the remaining circular segments are smaller than the excess.
若圆面积大于比较三角形 K,就不断平分圆弧并作内接多边形,使圆与多边形之间剩下的弓形总面积小于这个“多出来”的面积。
The inscribed polygon would then be greater than K, but every triangle from O to one side has height less than the radius and total base less than the circumference.
这样内接多边形会大于 K;但从 O 向每条边分成的小三角形,高小于半径,总底边小于圆周长,所以多边形又小于 K,矛盾。
If the circle were less than K, refine a circumscribed polygon until the outside strips are smaller than the excess of K over the circle.
若圆面积小于 K,就不断作外切多边形,使外切多边形和圆之间的余隙总面积小于 K 超过圆的那一块。
The circumscribed polygon would be less than K, but its apothem is the radius and its perimeter is greater than the circumference, so its area is greater than K.
于是外切多边形会小于 K;但它到每条边的垂距等于半径,周长又大于圆周长,所以面积大于 K,仍然矛盾。
The circle is neither greater nor less than K; therefore it is equal to K.
圆既不能大于 K,也不能小于 K,所以圆面积等于 K。
Modern notation writes this as A = 1/2 rC; when C = 2πr, it becomes A = πr².
现代写法是 A = 1/2 rC;再用 C = 2πr,才得到 A = πr²。这里真正重要的不是公式,而是双重反证的夹逼结构。
不看完整证明,说明“命题 1 · 圆面积与半径-周长直角三角形”这一命题的已知、要证和关键比较对象。
看一个提示
- 先把几何对象命名,再说它们之间要比较什么量。
- 穷竭法命题要特别留意“若大于”和“若小于”两边。
