数学 / 几何原本 / Proposition I.30

第1卷命题 30 · 同平行于一线的两线彼此平行

Straight lines parallel to the same straight line are also parallel to one another.

若两条直线都平行于同一条直线,则它们彼此也平行。

A B C D E F G H K
fig-1

三平行直线 AB、EF、CD;横截线 GK 交 AB 于 G,交 EF 于 H,交 CD 于 K。

线

正文图形由校订坐标生成;点、线、角、圆可与证明和问答联动。

分步证明Step-by-step proof
1 / 4
  1. Let each of the straight lines AB, CD be parallel to EF; I say that AB is also parallel to CD. For let the straight line GK fall upon them; Then, since the straight line GK has fallen on the parallel straight lines AB, EF, the angle AGK is equal to the angle GHF.

    设两条直线都平行于第三条直线。

  2. [I. 29] Again, since the straight line GK has fallen on the parallel straight lines EF, CD, the angle GHF is equal to the angle GKD.

    取一条横截线,分别使用 euclid-elements/book1-prop-029 得到相等的同位角。

  3. [I. 29] But the angle AGK was also proved equal to the angle GHF; therefore the angle AGK is also equal to the angle GKD; [C.N. 1] and they are alternate.

    由公理 1,这两条直线之间对应角也相等。

  4. Therefore AB is parallel to CD.

    再由 euclid-elements/book1-prop-028,它们彼此平行。
