第3卷命题 36 · 圆外一点引切线与割线定理

For let a point D be taken outside the circle ABC, and from D let the two straight lines DCA, DB fall on the circle ABC; let DCA cut the circle ABC and let BD touch it; I say that the rectangle contained by AD, DC is equal to the square on DB. Then DCA is either through the centre or not through the centre. First let it be through the centre, and let F be the centre of the circle ABC; let FB be joined; therefore the angle FBD is right. [III. 18] And, since AC has been bisected at F, and CD is added to it, the rectangle AD, DC together with the square on FC is equal to the square on FD.

设圆外一点D，过D作割线DCA和切线DB，需证AD·DC = DB²。

[II. 6] But FC is equal to FB; therefore the rectangle AD, DC together with the square on FB is equal to the square on FD. And the squares on FB, BD are equal to the square on FD; [I. 47] therefore the rectangle AD, DC together with the square on FB is equal to the squares on FB, BD. Let the square on FB be subtracted from each; therefore the rectangle AD, DC which remains is equal to the square on the tangent DB. Again, let DCA not be through the centre of the circle ABC; let the centre E be taken, and from E let EF be drawn perpendicular to AC; let EB, EC, ED be joined.

若DCA过圆心F，连接FB，则∠FBD为直角。由II.6，AD·DC + FC² = FD²；又FC=FB，且FB²+BD²=FD²，相减得AD·DC=DB²。

Then the angle EBD is right. [III. 18] And, since a straight line EF through the centre cuts a straight line AC not through the centre at right angles, it also bisects it; [III. 3] therefore AF is equal to FC. Now, since the straight line AC has been bisected at the point F, and CD is added to it, the rectangle contained by AD, DC together with the square on FC is equal to the square on FD. [II. 6] Let the square on FE be added to each; therefore the rectangle AD, DC together with the squares on CF, FE is equal to the squares on FD, FE.

若DCA不过圆心，取圆心E，作EF⊥AC，则AF=FC。由II.6，AD·DC+FC²=FD²；两边加FE²，得AD·DC+EC²=ED²。

But the square on EC is equal to the squares on CF, FE, for the angle EFC is right; [I. 47] and the square on ED is equal to the squares on DF, FE; therefore the rectangle AD, DC together with the square on EC is equal to the square on ED. And EC is equal to EB; therefore the rectangle AD, DC together with the square on EB is equal to the square on ED. But the squares on EB, BD are equal to the square on ED, for the angle EBD is right; [I. 47] therefore the rectangle AD, DC together with the square on EB is equal to the squares on EB, BD. Let the square on EB be subtracted from each; therefore the rectangle AD, DC which remains is equal to the square on DB.

因EC=EB，且EB²+BD²=ED²，相减得AD·DC=DB²。
