If a straight line be cut into equal and unequal segments, the squares on the unequal segments of the whole are double of the square on the half and of the square on the straight line between the points of section.
若一条直线既被等分又被不等分，则不等两段上的正方形之和，等于两倍半线上的正方形加两倍两分点间线段上的正方形。
AB 被 C 等分、D 不等分。在 C 处作 CE⊥AB 且 CE=AC=CB。连 EA、EB；过 D 作 DF∥CE 交 EB 于 F；过 F 作 FG∥AB 交 CE 于 G；连 AF。三角形 ACE 与 BCE 都是等腰直角，AEB 为直角。
正文图形由校订坐标生成；点、线、角、圆可与证明和问答联动。
For let a straight line AB be cut into equal segments at C, and into unequal segments at D; I say that the squares on AD, DB are double of the squares on AC, CD. For let CE be drawn from C at right angles to AB, and let it be made equal to either AC or CB; let EA, EB be joined, let DF be drawn through D parallel to EC, and FG through F parallel to AB, and let AF be joined. Then, since AC is equal to CE, the angle EAC is also equal to the angle AEC. And, since the angle at C is right, the remaining angles EAC, AEC are equal to one right angle. [I. 32] And they are equal; therefore each of the angles CEA, CAE is half a right angle.
一条线既被等分又被不等分，设两分点间距离为偏差。
For the same reason each of the angles CEB, EBC is also half a right angle; therefore the whole angle AEB is right. And, since the angle GEF is half a right angle, and the angle EGF is right, for it is equal to the interior and opposite angle ECB, [I. 29] the remaining angle EFG is half a right angle; [I. 32] therefore the angle GEF is equal to the angle EFG, so that the side EG is also equal to GF. [I. 6] Again, since the angle at B is half a right angle, and the angle FDB is right, for it is again equal to the interior and opposite angle ECB, [I. 29] the remaining angle BFD is half a right angle; [I. 32] therefore the angle at B is equal to the angle DFB, so that the side FD is also equal to the side DB. [I. 6] Now, since AC is equal to CE, the square on AC is also equal to the square on CE; therefore the squares on AC, CE are double of the square on AC.
把两个不等段分别看成半线加偏差、半线减偏差。
But the square on EA is equal to the squares on AC, CE, for the angle ACE is right; [I. 47] therefore the square on EA is double of the square on AC. Again, since EG is equal to GF, the square on EG is also equal to the square on GF; therefore the squares on EG, GF are double of the square on GF. But the square on EF is equal to the squares on EG, GF; therefore the square on EF is double of the square on GF. But GF is equal to CD; [I. 34] therefore the square on EF is double of the square on CD.
用第二卷前面矩形分解把两段平方展开为正方形和矩形部分。
But the square on EA is also double of the square on AC; therefore the squares on AE, EF are double of the squares on AC, CD. And the square on AF is equal to the squares on AE, EF, for the angle AEF is right; [I. 47] therefore the square on AF is double of the squares on AC, CD. But the squares on AD, DF are equal to the square on AF, for the angle at D is right; [I. 47] therefore the squares on AD, DF are double of the squares on AC, CD. And DF is equal to DB; therefore the squares on AD, DB are double of the squares on AC, CD.
相反的矩形部分抵消，留下两倍半线平方加两倍偏差平方。
